Stationary Concrete Batching Plant
ASURMAK STN-180 m3
ASURMAK STN-180 m³ is a powerful stationary concrete batching plant model designed for high-capacity and uninterrupted concrete production in large-scale projects.
CE Certified
2-Year Warranty
24/7 Technical Support
Fast Delivery
| ASURMAK STN-180 STATIONARY CONCRETE BATCHING PLANT — 180 m³/hour | ||
|---|---|---|
| FEATURES | VALUES | UNIT |
| Concrete Production Capacity | 180 | m³/hour |
| Mixer Type | Twin Shaft | Twin Shaft |
| Mixer Mixing Time | 30 | Seconds |
| Mixer Compacted Concrete Capacity | 4.5 | m³ |
| Mixer Dry Volume | 6.5 | m³ |
| Mixer Motor Power | 2×90 | kW |
| Number of Aggregate Compartments | 4 | Compartments |
| Aggregate Bin Capacity | 4×40 | m³ |
| Aggregate Weighing Conveyor | 1200×32000 | mm |
| Aggregate Weighing Capacity | 11,000 | kg |
| Cement Weighing Capacity | 2,250 | kg |
| Water Weighing Capacity | 1,150 | Lt |
| Additive Weighing Capacity | 2×50 | kg |
| Total Electrical Power | 286 | kW |
| Cement Silo | 100 | Ton |
| Cement Screw Conveyor | 323 | mm |
